Nozzle
Model 4120
High Frequency AC Nozzle Ionizer
Model 4120, equipped with Core Insight’s High Frequency AC technology, is a nozzle type ionizer. It can be applied to various processes such as PCB assembly process and back-end process with fast and powerful static electricity removal performance using compressed air.
The LED at the top allows you to easily check the operating status of the equipment even in the dark. Users can finely adjust the flow rate through the jog at the rear of the product, and remove compressed air motion through the connected Model 4111 IR Sensor.
The LED at the top allows you to easily check the operating status of the equipment even in the dark. Users can finely adjust the flow rate through the jog at the rear of the product, and remove compressed air motion through the connected Model 4111 IR Sensor.
video
FEATURES
- Stable ion balance
- Convenience in checking operation through LED & audio alarm
- Capable of controlling the operation of compressed air
- Ergonomic design considering usability
- low ion balance
- Hydraulic pressure and flow can be adjusted via controller
BENEFITS
- fast deionization time
- ON & OFF time-sensitive operation
- Individual control and display of output elements
- Large capacity control possible
SPECIFICATION
Input Voltage | 24 VDC, 4.1 W Max. | Monitoring | FMS monitoring interface |
Output Voltage | – | Air Pressure | 0.1 – 0.5 Mpa |
Ion Emission | High Frequency AC (70 kHz) | Air Inlet | 6mm Inlet |
Balance | Average ≤±10 V, Max ≤±30 V | Material | Enclosure: ABS Plastic Nozzle: Teflon Bracket: SUS |
Discharge Time | ±1000 V to ±100 V less than 1 sec (15cm) | Dimensions (mm) | 134W x 62H x 40D (with bracket) |
Emitter Points | Tungsten 99.99% | Weight | 170g (with bracket) |
Alarm | Visual & Audio alarm operate for power failures | Warranty | 1 year limited warranty |
